• Support GB18030,Multipleinternationallanguages.
• ESC/POS command compatibility.
• Support QRcode and IAP online.
• Compact Design With High Printing Speed Up to 230/260/300mm/s
| Model | |||||
| Resolution | 203 DPI | ||||
| Paper width | 58mm | 80mm | 83mm | ||
| Print width | 72mm | ||||
| Column capacity | 576 dots/line | ||||
| Printing speed | 230 mm/s | 260 mm/s | 300 mm/s | ||
| Interface | USB,USB+LAN,USB+LAN+Serial, USB+Bluetooth,USB+WIFI,USB+LAN+Serial+Bluetooth,USB+LAN+Serial+WIFI | ||||
| Character size | ANK,FontA: 1.5×3.0mm(12×24 dots) FontB: 1.1×2.1mm(9×17 dots) Simplified/Traditional Chinese:3.0×3.0mm(24×24 dots) | ||||
| Software parameters | |||||
| Extension character sheet | PC347(Standard Europe)/Katakana/PC85O(MuItilinguaI) /PC86O(Portugal)/sheet PC863(Canadian)/PC865(Nordic)/West Europe/Greek/Hebrew /East Europe/Iran/WPC1252/PC866(Cyrillic#2)/PC852(Latin2)/PC858/IranIl/Latvian /Arabic/PT151(1251) | ||||
| 1D Barcode | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 | ||||
| 2D Barcode | QR CODE/PDF417 | ||||
| Input buffer | 64Kbytes | ||||
| NV FIash | 64Kbytes | ||||
| Power | |||||
| Power adaptor | Input: AC 100~240V, 50~60Hz, 2.0A | ||||
| Printer Input | DC 24V/2.5A | ||||
| Cash drawer | DC 24V/1A | ||||
| Physical characteristics | |||||
| Weight | – | ||||
| Dimensions | 130 x 137 x 134mm(DxWxH) | ||||
| Environmental Requirements | |||||
| Work environment | Temperature (0~45C) humidity(10~80%) | ||||
| Storage environment | Temperature(-10~60°c) humidity(10~90%) | ||||
| Reliability | |||||
| Cutter life | 1.5 million cuts | ||||
| Printer head life | 150KM | ||||
| Software | |||||
| Emulation | ESC/POS | ||||
| Driver | Windows/Linux/Mac OS / Android | ||||
