• Space-saving design, 32 bit processo
• Ultra fast print speed :152 mm/s
• Bi-colored status LEDS for quick printerstatus
• Rich emulation language compatibility: TSPL,ZPL,EPL,DPL.
| Printer Specifications | |
| Resolution | 203DPI |
| Print method | Direct Thermal |
| Print speed | 152mm(6”)/s Max. |
| Max. Print width | 108 mm(4.25”) |
| Max. Print length | 1778 mm(70”) |
| Media | |
| Media type | Continuous, gap, black mark, fan-fold and punched hole |
| Media width | 26 mm ~ 116 mm |
| Media thickness | 0.06mm ~ 0.20mm |
| Label length | 10 ~ 1778 mm(0.39” ~ 70”) |
| Performance Features | |
| Processor | 32-bit CPU |
| Memory | 8MB Flash Memory/ 8MB SDRAM/ Flash memory can be expanded Max.4Gb |
| Interface | USB (Optional:Lan/Serial/ WIFI/BIuetooth/TF card) |
| Fonts/Graphics/Symbologies | |
| Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
| 1D barcode | Code 39,Code 93, Code 128UCC,Code 128 subsets A, B, C,Codabar, Interleaved 2 of 5,EAN-8,EAN-13,EAN-128,UPC-A,UPC-E,EAN and UPC 2(5)digits add-on,MSI, PLESSEY, POSTNET, China POST |
| 2D Bar Codes | PDF-417,Maxicode,DataMatrix,QR code |
| Rotation | 0° / 90° / 180° / 270° |
| Emulation | TSPL / EPL / ZPL / DPL |
| Physical Features | |
| Dimension | 195(W)×118(D)×100(H)mm |
| Weight | 0.913 kg |
| Reliability | |
| Warranty | One year for the printer |
| Print head | 30 km |
| Software | |
| Driver | Windows / Linux / Mac |
| SDK | Windows / iOS / Android |
| Power supply | |
| Input | AC 100-240V |
| Output | DC 24V=2.5A |
| Options | |
| Factory Options | ① Peeling machine ②Bluetooth ③WIFI ④Serial |
| Dealer Options | ①External paper roll holder and 1″ paper roll ②Extension board for external paper roll holder ③ Shipment waybill box |
| Environmental Conditions | |
| Operation | 5~40°C(41~104°F), Humidity:25~85% non-condensing |
| Storage environment | -40~60°C(-40~140°F), Humidity:10~90% non-condensing |
